POS8000

WINDOWS
Compact Embedded Box PC
Flytech's POS8000 is a powerful compact embedded Box PC built with a die-casting front cover and impact-resistant top and bottom covers. The space-saving and slim design make this unit a great fit for any space use. It features the advanced I/O ports to help handle all the workloads with efficiency. The fanless and low-power consumption design make the POS8000 an excellent choice for any type of business looking for a cost-effective embedded Box PC solution.
POS 8000
Slim and Fanless Embedded Box PC





Quiet work environment

Silent with fanless design

500x500


Compact mounting layout

Wall-mounted and desk-mounted available
by using the mounting brackets




500x500

Small but mighty

Maximize your workspace with a small footprint design

500x500

Specifications

Processor Intel Bay Trail CPU Celeron J1900
Intel Haswell CPU LGA-1150
Memory max. up to 8GB (DDR3)
Storage 1x 512G SSD or 2x 500GB HDD
Supported OS Windows 10 IoT Enterprise (64bit)
Graphic Engine Intel HD Graphics DX11
Expansion PCI-E Slot
Power Adapter Internal ATX 250W
EMC & Safety FCC Class B, CE Mark, LVD
Operating Temperature 0°C ~ 35°C (32°F ~ 95°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 20% ~ 85% RH non-condensing
Weight 1.9 kg (4.2 lbs)
Dimensions 270 x 220 x 50 mm (10.6" x 8.7" x 2.0")
External I/O Ports USB
Serial Port
LAN
Cash Drawer
VGA
Display Port
Audio Line-out
Parallel Port
PS/2
Kensington Lock
Options Powered USB + LAN
Wireless LAN
Wall Mount Kit
motherboard
os
file name

D36
Other
POS8000 (D36, D66) DM
D66
Other
POS8000 (D36, D66) DM
